Sangroove (Jiangsu) Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of simo turbocharger housing in China. If you're going to wholesale cheap simo turbocharger housing made in China, welcome to get pricelist from our factory. All customized products are with high quality and low price.
Product Overview
The SiMo Turbocharger Housing is a structural component of a turbocharging system. Depending on the assembly design, the housing may include the turbine housing, compressor housing, or center housing. These components accommodate the turbocharger's rotating assembly and gas-flow passages while providing the mounting interfaces required for engine integration.
The turbine housing is exposed to hot exhaust gases, making heat resistance and thermal fatigue performance important material considerations. High-silicon molybdenum iron (SiMo) is used in suitable turbocharger applications where resistance to elevated temperatures and repeated heating and cooling is required.
Sangroove manufactures customized turbocharger housings using casting and machining processes selected according to component geometry, material requirements, and production specifications. CNC machining and dimensional inspection help meet the required assembly interfaces and drawing tolerances.
Manufacturing Process
Component Design and Casting Process Optimization
Mold Design and Manufacturing
Shell Mold Casting
High-Silicon Molybdenum Iron Melting and Composition Control
Resin Sand Casting, Where Applicable
Lost Foam Casting, Where Applicable
Heat Treatment, According to Material Requirements
CNC Precision Machining
Air Tightness Testing, Where Required
Dimensional Inspection and Coordinate Measurement
Metallographic Analysis and Material Verification
Additional Performance Testing According to Customer Specifications
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | SiMo Turbocharger Housing |
| Types | Turbine Housing / Compressor Housing / Center Housing |
| Primary Material | High-Silicon Molybdenum Iron (SiMo) |
| Optional Materials | Heat-Resistant Cast Steel, Stainless Steel, High-Nickel Alloy |
| Weight Range | 1–80 kg |
| Operating Temperature | 650°C–1050°C, subject to material grade and application conditions |
| Casting Processes | Shell Mold / Resin Sand / Lost Foam Casting |
| Machining Accuracy | ±0.02 mm |
| Inspection Options | Air Tightness Testing, Metallographic Analysis, CMM Inspection |
| Applications | Automotive Engines, Diesel Engines, Turbocharging Systems |
Product Advantages
Heat-Resistant SiMo Material: Suitable SiMo grades can support turbocharger housing applications exposed to elevated exhaust temperatures.
Thermal Cycling Considerations: Material selection and component design can be evaluated for repeated heating and cooling conditions.
Complex Casting Geometry: Casting processes support the production of housing shapes and integrated gas-flow passages.
Precision-Machined Interfaces: CNC machining helps achieve the specified mounting dimensions and assembly fit.
Material Composition Control: Melting and composition control help maintain compliance with agreed material specifications.
Customized Inspection: Dimensional, metallographic, and air-tightness inspections can be arranged according to product requirements.
Customer Benefits
Application-Matched Material Selection: Material options can be reviewed against the expected exhaust temperature and thermal cycling conditions.
Reliable Assembly Integration: Machining of mounting faces and connection interfaces helps meet specified assembly requirements.
Flexible Component Development: Housing geometry and manufacturing specifications can be customized for different turbocharger designs.
Coordinated Manufacturing: Casting, machining, and inspection services can be managed within one manufacturing workflow.
Quality Verification: Inspection plans can be aligned with agreed drawings, material specifications, and customer acceptance criteria.
OEM Production Support: Manufacturing arrangements can be tailored to approved prototypes and ongoing production orders.
Why Choose Sangroove
40+ Years of Casting Experience: Experience manufacturing cast components for automotive and industrial applications.
Multiple Casting Capabilities: Shell mold, resin sand, lost foam, and green sand processes are available according to product suitability.
Material and Process Control: Support for alloy composition control and manufacturing process selection.
Integrated Manufacturing Services: Mold development, casting, CNC machining, surface treatment, and inspection.
Quality Management Systems: The company reports certifications including IATF 16949, ISO 9001, ISO 14001, ISO 45001, ISO 10012, and ISO 50001. Applicable certification scopes can be confirmed upon request.
Inspection Equipment: Available equipment is reported to include an OBLF spectrometer, ZEISS measurement equipment, X-ray inspection, UT/MT systems, and air-tightness testing systems, subject to project requirements.
OEM Customization Support: Manufacturing based on customer drawings, material requirements, machining specifications, and agreed inspection criteria.
Applications
Exhaust-Side Turbine Housings: Cast housings designed to accommodate hot exhaust gas flow into the turbocharger turbine.
Compressor-Side Housing Assemblies: Housing components for the compressor section, subject to the selected material and design requirements.
Turbocharger Center Housing Components: Customized cast components for compatible center-section designs, where the specified material is suitable.
Heavy-Duty Diesel Turbochargers: Housings for commercial vehicle and industrial diesel engine boosting systems.
Construction Machinery Engine Systems: Turbocharger housing components for compatible off-highway engine platforms.
Agricultural Machinery Powertrains: Customized housings for turbocharged agricultural engine applications.
Industrial Engine and Generator Sets: Cast housing components for compatible stationary engine turbocharging systems.
Marine Diesel Engine Turbocharging: Application-specific housings for marine engine systems, subject to material and operating-condition validation.
FAQ
Q1: What is a SiMo Turbocharger Housing?
It is a cast structural component used in a turbocharger system. Depending on the design, it may serve as the turbine housing, compressor housing, or center housing.
Q2: What material is used for SiMo turbocharger housings?
The specified primary material is high-silicon molybdenum iron (SiMo). Other listed options include heat-resistant cast steel, stainless steel, and high-nickel alloy, subject to technical review.
Q3: Can you manufacture housings according to customer drawings?
Yes. Customized casting and machining can be evaluated according to customer drawings, sample components, dimensional requirements, and material specifications.
Q4: What operating temperatures can the product withstand?
The supplied specifications list 650°C–1050°C. Actual suitability depends on the selected material grade, local temperature exposure, thermal cycling, component design, and operating conditions. Confirm the applicable temperature range for each project.
Q5: What inspection services are available?
The listed options include air-tightness testing, metallographic analysis, and coordinate measuring machine inspection. Additional testing should be agreed upon according to the product design and customer quality requirements.
Q6: What information is needed for a quotation?
Please provide the housing drawing or sample details, material grade, estimated order quantity, machining requirements, operating conditions, and required inspection standards. Our team can review the specifications and assess manufacturing feasibility.
